3 Gang Cube Mould 100mm/150mm, Mild Steel

Standard: EN 12390-1, ASTM C39/C192, AASHTO T23/T126, BS 1881:108

3 Gang Cube Mould 100mm/150mm, Mild Steel

3 Gang Cube Mould is used to create 3 standardized concrete cube samples simultaneously with 100mm and 150mm sizes for testing purposes. These moulds are typically made from mild steel, a type of low-carbon steel known for its strength and durability.

The purpose of 3 Gang Cube Mould is to prepare concrete specimens for testing purposes. These specimens are often subjected to compressive strength tests to assess the quality and performance of the concrete. By creating uniform and standardized cube samples using the moulds, engineers, and technicians can ensure consistency in testing procedures and obtain reliable data on the strength and durability of the concrete material.

Feature of 3 Gang Cube Mould 100mm/150mm, Mild Steel

• Creates cube-shaped concrete samples of consistent dimensions for accurate testing.
• Mild steel offers stability and reliability in maintaining shape and dimensions during the concrete curing process.
• Designed for easy handling and manipulation during concrete casting and demoulding processes.
• Helps maintain quality control by ensuring standardized testing procedures and reliable data collection.

Standard

• EN 12390-1: European standard outlining procedures for testing the compressive strength of concrete specimens.
• ASTM C39/C192: American standards provide guidelines for testing the compressive strength and density of concrete.
• AASHTO T23/T126: Standards from the American Association of State Highway and Transportation Officials (AASHTO) detailing procedures for testing the density and compressive strength of concrete.
• BS 1881:108: British standard specifying methods for testing the compressive strength of concrete samples in laboratory settings.

Test Procedure for 3 Gang Cube Mould 100mm/150mm, Mild Steel

1. Preparation: Ensure the mild steel cube mould is clean and free from any debris or residues. Check for any damage or irregularities in the mould.
2. Lubrication: Apply a thin layer of mould release agent or lubricant to the interior surfaces of the mould to prevent the concrete from sticking.
3. Concrete Mix Preparation: Prepare the concrete mix according to the desired specifications, ensuring the correct proportions of cement, aggregates, and water are used.
4. Filling the Mould: Place the clean and lubricated mild steel cube mould on a flat surface. Fill the mould with freshly mixed concrete, ensuring it is evenly distributed and compacted.
5. Surface Smoothing: Use a trowel or float to level the surface of the concrete and remove any excess material.
6. Curing: Cover the filled mould with a damp cloth or plastic sheeting to prevent moisture loss and promote proper curing of the concrete. Allow the concrete to cure for the specified time period.
7. Demoulding: After the curing period has elapsed, carefully remove the mild steel cube mould from the concrete specimen. Use caution to avoid damaging the edges or corners of the cube.
8. Storage: Transfer the demoulded cube specimen to a curing room or designated storage area. Ensure it is protected from environmental factors such as temperature fluctuations and excessive moisture.
9. Testing: After the specified curing period, the cube specimen is ready for testing. Conduct compressive strength tests according to relevant standards such as ASTM C39 or EN 12390-3.
10. Documentation: Record all relevant information, including the date of casting, mix proportions, curing conditions, and test results. Compile the data into a comprehensive report for further analysis and documentation.

Technical Specifications for 3 Gang Cube Mould 100mm/150mm, Mild Steel
