Concrete Testing Equipments

nl4000x020-01
Standard: EN 12390-4, ASTM C39, AASHTO T22, UNI   Newly upgraded model, rigid, compact & with brand new outlook. Old AC motor had replaced by new imported DC motor for more durability, low noise pollution, low oil temperature & low power consumption. Extra improvement on safety feature wit ...Read more

Eco Smartz Computerized Fully Automatic Welded Frame Compression Machine 3000kN
NL 4000 X / 020




  • Description

Standard: EN 12390-4, ASTM C39, AASHTO T22, UNI



Newly upgraded model, rigid, compact & with brand new outlook. Old AC motor had replaced by new imported DC motor for more durability, low noise pollution, low oil temperature & low power consumption. Extra improvement on safety feature with fully protection cover & piston travel protection switch cover.

FEATURES:-
*High energy saving up to 70% compare with conventional type
*Extremely low sound & vibration during operation
*User friendly computerised system
*Original genius parts cost low maintenance
*Free from foundation mounting
*Fully covered safety enclosed

SOFTWARE SUPER TEST 9.1
*User friendly one click RUN to operate & clear menu display indication
*Options to select number of decimal points to display for Load, Strength & Speed.
*Real time display of Load against Time curve & options to display curve in test report.
*Number of samples per report can be added up to 10 samples.
*Unlimited savings of test result in huge computer storage memory.
*User input of Test Number, Strength, Age, Sample Size (cube, block & cylinder) & Loading Speed
*Test report can be printed immediately after test with a printer connected.
*Test report header can be input manually for various information such as customer information, weight, mixing ratio, project, etc.
*Simple automatic or manual loading for calibration with auto correction function for load error.
*Software consists of dual programes for compression & flexural tests.



Technical Specifications :

 Model Number  NL 4000 X / 020
 Max. Vertical Clearance  350 mm
 Max. Horizontal Clearance  290 mm
 Capacity  3000 kN x 1.0 kN Sensitivity
 Compression Platen Diameter  300 mm
 Piston Ram Diameter  300 mm
 Piston Ram Travel Column Diameter  80 mm
 Accuracy  Class 1
 Loading Rate Range  1 kN / s
 Relative Error  ±1%
 Repeatability Relative Error  1%
 Zero Drift  ±0.1%
 Resolution  0.5%
 Sensor Accuracy  0.1%
 Max. Hydraulic Working Pressure  25 MPa
 Product Dimension (mm)  960 (L) x 500 (W) x 1200 (H)
 Packing Dimension (mm)  1060 (L) x 600 (W) x 1450 (H)
 Approx. Product Weight  900 kg
 Approx. Packing Weight  1000 kg
 Power  0.75 KW
