Eco Smartz Automatic Touch Screen Compression Machine 2000kN
NL 4000 X / 016U




  • Description

Standard: EN 12390-3, ASTM C39, AASHTO T22



Compression And Flexural

Newly upgraded model with brand new outlook. Old AC motor replaced by new imported DC motor for more durability, low noise pollution, low oil temperature & low power consumption.

FEATURES:-
*Energy saving
*Less vibration & noise
*Auto result saving up to 450 specimen
*Simple operation system
*Dual channels ready for compression & flexural
*Piston travel switch

ADDITIONAL FEATURE :-
*Upgraded fully covered safety enclosed
*Extended base frame for comfortable operation level
*USB port to export test result



Technical Specifications :

 Model Number  NL 4000 X / 016U
 Max. Vertical Clearance   425 mm
 Max. Horizontal Clearance  270 mm
 Capacity  2000 kN
 Low Range Sensitivity  0 - 999 x 0.1 kN
 High Range Sensitivity  1000 - 2000 x 1kN
 Compression Platen Diameter  295 mm
 Piston Ram Diameter  250 mm
 Piston Ram Travel  50 mm
 Column Diameter  Ø70 mm
 Accuracy  Class 1
 Product Dimension (mm)  970 (L) x 610 (W) x 1300 (H)
 Packing Dimension (mm)  1020 (L) x 650 (W) x 1400 (H)
 Approx. Product Weight  783 kg
 Approx. Packing Weight  805 kg
 Power  220 V, 2.5 Amp, 50 / 60 Hz, 1 ph
