Zehntner Marking Retroreflection
ZRM 6014 RL-Qd
Day and night visibility measurement of road markings with retroreflectometry.

Fold-away telescopic handle
Ultrafast retroreflection measurement
Precise geolocation and high-res images.

Applications:
Determination of day visibility (Qd) of road and airport markings / Determination of night visibility (RL) of road and airport markings / Use on all types of road and airport markings / Field and laboratory use / Quality assessment

Technical Specifications:

Model Number	ZRM 6010 RL
Technology	High-resolution Camera Optional compass and level-meter GPS, internal printers
Display	Touchscreen 5.7“ colour TFT (LCD), LED backlight, VGA resolution
Memory	1 GB internal flash memory
Measurement Modes	RL dry (night visibility) RL wet (night visibility) Qd (day visibility) °C/°F (ambient temperature) rH % (relative humidity)
Measuring Area	(WxL): 52 mm x 218 mm (2.05" x 8.58")
Measuring Range	RL: 0 - 4’000 mcd•m-2•lx-1 Qd: 0 - 400 mcd•m-2•lx-1
Measuring Accuracy	Repeatability ± 2 %
Observation Angle	EN 1436: 2.29° ASTM E1710: 1.05°
Calibration Accuracy	EN 1436: 1.24° ASTM E1710: 88.76°
Illumination Angle	RL: EN 1436: 1.24° RL: ASTM E1710: 88.76° Qd: diffuse
Reporting software	Includes mapping and data analysis software MappingTools
Weight	7.6 kg (16.76 lbs)
Operating Temperature	-10°C to +50°C (14°F to 122°F)
