Zehntner Sign Retroreflection
ZRS 6060

BY EMAIL

By Whatsapp

PRODUCT DETAIL

Description

Zehntner Sign Retroreflection
ZRS 6060
Visibility measurement of traffic and road signs and reflective materials

Easy to operate with polyglot menu navigation
Sturdy construction and ergonomic design
Precise geolocation and high-resolution images

Applications:
Determination of the Coefficient of Retroreflection RA and R' / Automatic colour indication of retroreflective materials / Field and laboratory use / Quality assessment

Technical Specifications:

Model Number	ZRS 6060
Configuration	Innovative options to customize the reflectometer to personal requirements: integrated 5-megapixel camera, WAAS GPS-unit, handles and many more
Technology	LED illumination system 3.5” colour touchscreen with adjustable display inclination for excellent visibility under all light conditions Measurement of three different observation angles at the same time
Display	3.5“ colour TFT (LCD), LED backlight, HVGA resolution
Memory	Internal flash memory of 1 GB ≈ 1‘000‘000 measurements without pictures
Connections	Host USB (type A, Client Mini USB)(type B)
Measuring Range	0 - 2‘000 cd•lx-1•m-2
Reporting software	Includes mapping and data analysis software MappingTools
Calibration Accuracy	Factory calibration traceable to the independent Swiss Federal Institute of Metrology METAS
Weight	1.9 kg (4.19 lbs) net without options
Battery	Li-Ion 14.4 V / 6.5 Ah
Operating Temperature	-10 to +50°C (14 to +122°F), non condensing
