Concrete Testing Equipments

Product Range

Standard: EN 12390-2, BS 1881-108, UNI 6127 Concrete Compaction For use in laboratory to vibrate cylinder and cube specimens or compaction of concrete specimens. Robustly manufactured to operate with minimum noise level. Equipped with motor having 3000 / 3600 r.p.m. vibration per minutes. The ...Read more

Vibrating Table
NL 4015 X /

BY EMAIL

By Whatsapp

PRODUCT DETAIL

Description

Standard: EN 12390-2, BS 1881-108, UNI 6127

Concrete Compaction

For use in laboratory to vibrate cylinder and cube specimens or compaction of concrete specimens. Robustly manufactured to operate with minimum noise level. Equipped with motor having 3000 / 3600 r.p.m. vibration per minutes. The vibrating table fitted with clamping device and Pedal Switch or Control Panel (Upon Request).

Technical Specifications :

Model Number	NL 4015 X
Vibrating Frequency	3000 rpm / 50 Hz & 3600 rpm / 60 Hz
Power	220~240 V, Single Phase

Available Modes :

Model Number	Table Size (mm)	Power (W)	Hp	Amperes (A)	Weight (kg)	No. Mould
NL 4015 X / 001	700 x 400	100	0.134	0.54	70	2
NL 4015 X / 002	1000 X 400	180	0.25	1.14	74.5	4
NL 4015 X / 004	1300 x 1000	180 x 2	0.25 x 2	1.14 x 2	159	12
NL 4015 X / 005	610 x 1000	180	0.25	1.14	90	6

*1 Copy of Manual Instruction
